Ceramic Glass Panel For Fireplace
Crystallite glass is made of a special glass-ceramic, a material with fascinating properties. This glass-ceramic has extraordinary thermal stability and resists thermal shocks of up to +700 degree C. It stands up to everyday wear and tear in the kitchen. The 4mm thick cooktop panel transmits heat very efficiently, with virtually no heat loss.
|
|  |
Ceramic Glass Features
1. Glass ceramic is resisting to heat and cold, even to extreme temperature changes.
This extraordinary property enables a variety of applications: cooking on glass ceramic appliances day after day , and protecting your fire places or stoves, still enjoying flames view.
2. Among the heat resistant glasses, glass ceramic is really special. Its key property, is low thermal expansion, lower than borosilicate glasses or standard glasses. It means that, unlike most materials, the crystallite glass ceramic will not expand nor contract with heat. It barely changes its dimensions. This is the reason behind efficient and long time resistant cooktops.
|
Mechanical strength | Density | Elastic seeks | Bending strength |
2.6g/cm³ | 93*103Mpa | 35Mpa | |
Thermodynamic Performance | Average coefficient of linear thermal expansion | Identical temperature difference | Thermal shock resistance |
a(20-800℃):(0±0.5)*10-6/K | (RTD) ≤760℃ | Tes max≦760℃ no break | |
Application Temperature and Continuous operating time | Application temperature | Continuous operating time | |
560℃ | 20000h | ||
610℃ | 9000h | ||
660℃ | 4500h | ||
710℃ | 1200h | ||
800℃ | 500h | ||
Chemical performance | Acid resistance | Alkali resistance | |
DIN12116 HGB1 | DIN ISO719 HGB2 | ||
Glass Variety | Transparent microcrystalline glass，Dark brown microcrystalline glass with ball-point | ||
Machinable shape | Square，circle，R-corner and any irregular shape | ||
microcrystalline glass Application | Wave soldering, microwave oven, Convection Oven, electric radiator, fireplaces, induction cooker glass plate. High-Performance flood light, metal halide lamp, infrared dryer,etc and Photovoltaic solar equipment shield | ||
Ceramic Glass Applications
1.Vision panels for room heaters, glass heaters, glass heating tabletops, heat preservation board/panels;
2.Cover panels for heating radiators, drying stand, towel heaters;
3.Cover panels for reflectors and high performance floodlights
4.Cover panels in IR drying appliances
5.Cover panels for beamers
6.UV blocking shields
7.Cover panels for kebab grill radiators, electric heating fish bowl
|
Available Size
4mm 5mm 150*150mm,320x400mm, 400*800mm,600*700mm, 1100x1954mm.etc.（also with custom size based on your command)
The product price is for reference only and does not represent the specific selling price. Because there are too many product sizes, parameters need to be provided for processing. Outer diameter, thickness, length and quantity. For the length, width, thickness and quantity of square pieces, it is best to provide the drawing mailbox so that we can make an accurate quotation
